International Air Freight Container Sizes |
|
|
| |
Aircraft / Air Freight containers or ULD's (Unit Loading Devices) vary in capacity from AKE with an internal volume of 4.3cbm up to AMA with an internal volume of 17.5cbm, capable of taking 1,588kg and 6,804kg respectively.
Please note:
Please use the following dimensions as indications only. These approximate dimensions will vary slightly depending on the age and manufacturer of the aircraft / air freight containers. |
|
|
| |
|
|
|
| |
| AMA - Air Freight Container |
|
| ATA Code: M1 |
Weight Limitations Inc: |
| Internal Volume: 621cu. ft 17.58mc |
ULD Tare Weight: 6,804kg |
| Tare Weight: 360kg |
|
|
|
| Exterior Dimensions: |
Loadable Aircraft Type: |
| Length: 3,180mm (10' 5" ft) |
747F |
| Width: 2,240mm (7' 4" ft) |
|
| Height: 2,240mm (7' 4" ft) |
|
|
|
|
|
|
| |
------------------------------------------------------------------------------------------------------------------------------------ |
|
| |
| AMF - Air Freight Container |
| |
|
| ATA Code: N/A |
Weight Limitations Inc: |
 |
| Internal Volume: 516cu. ft 14.6mc |
ULD Tare Weight: 5,035kg |
| Tare Weight: 330kg |
|
|
Loadable Aircraft Type: |
|
|
|
| |
------------------------------------------------------------------------------------------------------------------------------------ |
|
|
| |
| AMA - Air Freight Container |
|
| ATA Code: M1 |
Weight Limitations Inc: |
 |
| Internal Volume: 621cu. ft 17.58mc |
ULD Tare Weight: 6,804kg |
| Tare Weight: 360kg |
|
|
|
| Exterior Dimensions: |
Loadable Aircraft Type: |
| Length: 3,180mm (10' 5" ft) |
747F |
| Width: 2,240mm (7' 4" ft) |
|
| Height: 2,240mm (7' 4" ft) |
|
|
|
|
|
|
| |
------------------------------------------------------------------------------------------------------------------------------------ |
|
|
| |
| AMF - Air Freight Container |
|
| ATA Code: N/A |
Weight Limitations Inc: |
 |
| Internal Volume: 516cu. ft 14.6mc |
ULD Tare Weight: 5,035kg |
| Tare Weight: 330kg |
|
|
Loadable Aircraft Type: |
| Exterior Dimensions: |
747, 747F, 777, Airbus |
| Max Length: 4,070mm (13' 3" ft) |
|
| Width: 2,440mm (8' 0" ft) |
|
| Max Height: 1,630mm (5' 4" ft) |
|
|
|
|
|
|
| |
------------------------------------------------------------------------------------------------------------------------------------ |
|
|
| |
| AMU - Air Freight Container |
| ATA Code: LD39 |
Weight Limitations Inc: |
|
| Internal Volume: 557cu. ft 15.77mc |
ULD Tare Weight: 5,035kg |
| Tare Weight: 290kg |
|
|
Loadable Aircraft Type: |
| Exterior Dimensions: |
747, 747F |
| Max Length: 4,730mm (15' 6" ft) |
|
| Width: 2,440mm (8' 0" ft) |
|
| Max Height: 1,630mm (5' 4" ft) |
|
|
|
| Back to top |
|
|
|
| ------------------------------------------------------------------------------------------------------------------------------------ |
| ALF - Air Freight Container |
|
| ATA Code: LD6 |
Weight Limitations Inc: |
 |
| Internal Volume: 310cu. ft 8.78mc |
ULD Tare Weight: 3,175kg |
| Tare Weight: 155kg |
|
|
|
| Exterior Dimensions: |
Loadable Aircraft Type: |
| Max Length: 4,070mm (13' 3" ft) |
747, 747F, 777, Airbus |
| Width: 1,540mm (5' 0" ft) |
|
| Max Height: 1,630mm (5' 4" ft) |
|
|
|
| Back to top |
|
|
|
| ------------------------------------------------------------------------------------------------------------------------------------ |
| AAU - Air Freight Container |
|
| ATA Code: LD29 |
Weight Limitations Inc: |
 |
| Internal Volume: 505cu. ft 14.3mc |
ULD Tare Weight: 4,626kg |
| Tare Weight: 355kg |
|
|
|
| Exterior Dimensions: |
Loadable Aircraft Type: |
| Max Length: 4,730mm (15' 6" ft) |
747, 747F |
| Width: 2,240mm (7' 4" ft) |
|
| Max Height: 1,630mm (5' 4" ft) |
|
|
|
|
|
|
| |
------------------------------------------------------------------------------------------------------------------------------------ |
|
|
| |
| AAP - Air Freight Container |
| ATA Code: LD9 |
Weight Limitations Inc: |
|
| Internal Volume: 371cu. ft 10.51mc |
ULD Tare Weight: 4,626kg |
| Tare Weight: 222kg |
|
|
|
| Exterior Dimensions: |
Loadable Aircraft Type: |
| Length: 3,180mm (10' 5" ft) |
747, 747F, 777, Airbus |
| Width: 2,240mm (7' 4" ft) |
|
| Height: 1,630mm (5' 4" ft) |
|
|
|
| Back to top |
|
|
|
| ------------------------------------------------------------------------------------------------------------------------------------ |
| RAP 'Cooltainer' - Air Freight Container |
|
| ATA Code: LD9 |
Weight Limitations Inc: |
 |
| Internal Volume: 352cu. ft 9.2mc |
ULD Tare Weight: 4,626kg |
| Tare Weight: 330kg |
|
|
|
| Exterior Dimensions: |
Loadable Aircraft Type: |
| Length: 3,180mm (10' 5" ft) |
747, 747F, 777, Airbus |
| Width: 2,240mm (7' 4" ft) |
|
| Height: 1,630mm (5' 4" ft) |
|
|
|
| Back to top |
|
|
|
| ------------------------------------------------------------------------------------------------------------------------------------ |
| RKN 'Cooltainer' - Air Freight Container |
|
| ATA Code: LD3 |
Weight Limitations Inc: |
 |
| Internal Volume: 125.41cu. ft 3.55mc |
ULD Tare Weight: 1,588kg |
| Tare Weight: 190kg |
|
|
|
| Exterior Dimensions: |
Loadable Aircraft Type: |
| Max Length: 2,010mm (6' 7" ft) |
747, 747F. 777, Airbus |
| Width: 1,540mm (5' 0" ft) |
|
| Height: 1,630mm (5' 4" ft) |
|
|
|
| |
|
|
|
| ------------------------------------------------------------------------------------------------------------------------------------ |
| AKE - Air Freight Container |
| ATA Code: LD3 |
Weight Limitations Inc: |
|
| Internal Volume: 152cu. ft 4.3mc |
ULD Tare Weight: 1,588kg |
| Tare Weight: 100kg |
|
|
Loadable Aircraft Type: |
| Exterior Dimensions: |
747. 747F, 777, Airbus |
| Max Length: 2,010mm (7' 7" ft) |
|
| Width: 1,540mm (5' 0" ft) |
|
| Max Height: 1,630mm (5' 4" ft) |
|
|
|
| Back to top |
|
|
|
| ------------------------------------------------------------------------------------------------------------------------------------ |
| AVJ - Air Freight Container |
|
| ATA Code: LD1 |
Weight Limitations Inc: |
 |
| Internal Volume: 162cu. ft 4.80mc |
ULD Tare Weight: 1,588kg |
| Tare Weight: 100kg |
|
|
|
| Exterior Dimensions: |
Loadable Aircraft Type: |
| Max Length: 2,340mm (7' 8" ft) |
747, 747F. |
| Width: 1,540mm (5' 0" ft) |
|
| Max Height: 1,630mm (5' 4" ft) |
|
|
|
|
|
|
| |
|
|
|
| |
|
|
|
| |
|
|
|
| |
|
|
|
